3

Is there a name for this type of effect where many area sizes are increased/decreased in relation to each other? I'm looking for some type of algorithm, formula, logic, etc. for recreating this. Here is the effect (which I believe was created in After Effects):

The Tatami Galaxy (Yojouhan Shinwa Taikei / 四畳半神話大系) - Clear END

Source: The Tatami Galaxy (Yojouhan Shinwa Taikei / 四畳半神話大系) - Clear END

Sosa
  • 133
  • 3
  • I think perhaps it might be "constraint-based" or "rule-based" modelling.

    Ivan Sutherland's sketchpad program (https://en.wikipedia.org/wiki/Sketchpad) perhaps may have been the first.

     – Simon F Jan 18 '19 at 16:46

1 Answers1

7

It looks like a voronoi diagram with a non-Euclidean distance metric. Probably not Manhattan L1 but something close related, but maybe Mahalanobis with some kind of restriction on seed point generation and movement.

A similar result may be calculated with Weight-proportional Space Partitioning Using Adaptive Voronoi Diagrams when reducing spatial resolution of the domain.

I guess yo'll find similar examples in ShaderToy if you look for voronoi examples, which code you could study, and could be much simpler than the algorithm in the paper.

David
  • 301
  • 2
  • 4
  • This looks very close to what I was looking for thank you! Question though, is there a related formula on how to achieve the rectangular effect for each node? From what I've looked into it seems like all examples have voronoi diagrams with polygons. The weight-proportional paper had a rectangular image on google but this paper is paywalled. – Sosa Jan 18 '19 at 23:30
